Peb muab rotary vane nqus twj tso kua mis rau Becker
VT4.4 / VT4.8 / VT4.10 / VT4.16 / VT4.25 / VT4.40 / KVT3.60 / KVT3.80 / KVT3.100 / KVT3.140 / DVT3.80 / DVT3.140 / VTLF2. 250 / DVTLF2.250 / KDT3.80 / KDT3.140 / PICCH10 2200 / T4.40DSK / VT4.16 / GV8 / U5.40 / U5.71 / U5.101 / U5.166 / U5.201 / U5.301 .Yog tias koj xav tau becker nqus tsev vacuum twj, thov qhia rau peb paub.
Becker roj lub tshuab nqus tsev twj
Becker Pumps data sheet
| Qauv NO. | Ceev tus nqi | Qhov kawg siab | Lub cev muaj zog | Suab nrov | Qhov hnyav | |||
| m³/h | KPA | KW | dB (A) | kg | ||||
| 50hz ib | 60hz ib | 50 HZ | 60 tzs | 50 HZ | ||||
| VT 4.4 | 4.1 | 4.7 | 15 | 1 phn | 0.18 | 0.21 | 59 | 7 |
| 3 phn | 0.18 | 0.21 | ||||||
| VT 4.8 | 8 | 9.1 | 15 | 1 phn | 0.35 | 0.42 | 58 | 9.5 |
| 3 phn | 0.37 | 0.44 | 58 | |||||
| VT 4.10 | 10 | 12 | 15 | 1 phn | 0.37 | 0.44 | 60 | 16 |
| 3 phn | 0.37 | 0.45 | 60 | |||||
| VT4.16 | 16 | 19 | 15 | 1 phn | 0.55 | 0.66 | 61 | 22.5 |
| 3 phn | 0.55 | 0.70 | ||||||
| VT4.25 | 25 | 30 | 15 | 1 phn | 0.8 | 1.1 | 62 | 26 |
| 3 phn | 0.75 | 0.9 | ||||||
| VT 4.40 | 40 | 48 | 15 | 1 phn | 1.1 | 1.1 | 67 | 38.5 |
| 3 phn | 1.25 | 1.5 | ||||||
| KVT 3.60 | 55 | 66 | 10 | 2.2 | 2.6 | 71 | 84 | |
| KWV 3.80 | 67 | 78.5 | 10 | 2.2 | 2.6 | 72 | 86 | |
| KVT 3.100 | 98 | 112 | 10 | 3 | 3.6 | 75 | 108 | |
| KWV 3.140 | 129 | 154 | 10 | 4 | 4.8 | 76 | 142.5 | |
| VTLF2.200 | 178 | 218 | 20 | 4 | 4.8 | 75 | 265 | |
| VTLF 2.250 | 244 | 286 | 20 | 5.5 | 6.6 | 77 | 258 | |
| VTLF2.360 | 351 | 402 | 15 | 11 | 13.2 | 80.5 | 263 | |
| VTLF 2.400 | 390 | 460 | 20 | 7.5 | 9 | 77 | 425 | |
| VTLF 2.500 | 495 | 570 | 25 | 11 | 13.2 | 79 | 411 | |
| Qauv NO. | Ceev tus nqi | Qhov kawg siab | Lub cev muaj zog | Suab nrov | Qhov hnyav | |||
| m³/h | KPA | KW | dB (A) | kg | ||||
| 50hz ib | 60hz ib | 50 HZ | 60 tzs | 50 HZ | ||||
| T4.10 DV | 9.5 | 11.7 | ±50 | 1 phn | 0.37 | 0.44 | 55 | 16 |
| 3 phn | 0.37 | 0.45 | ||||||
| T4.16 DV | 15.5 | 18.1 | ±50 | 1 phn | 0.55 | 0.66 | 61 | 24 |
| 3 phn | 0.55 | 0.7 | ||||||
| T4.25 DV | 23.6 | 28.3 | ±50 | 1 phn | 0.8 | 1.1 | 69 | 26 |
| 3 phn | 0.75 | 0.9 | ||||||
| T4.40 DV | 35.9 | 42.5 | ±50 | 1.25 | 1.5 | 66 | 38.5 | |
| T4.25 DSK | 23.4 | 28.5 | ±60 | 1 phn | 1.1 | 69 | 35 | |
| 3 phn | 1.1 | 1.3 | ||||||
| T4.40 DSK | 34.5 | 42.1 | ±60 | 1.85 | 2.2 | 68 | 46 | |
| TSI 3.60 | 55.2 | 65 | ±50 | 2.2 | 2.6 | 75 | 84 | |
| 54.6 | 63.8 | ±60 | 3 | 3.6 | ||||
| TSI 3.80 | 63.9 | 76.5 | ±50 | 4 | 4.8 | 76 | 113.5 | |
| 63 | 76 | ±60 | 4 | 4.8 | ||||
| TSI 3.100 | 95.6 | 113.7 | ±50 | 5.5 | 6.6 | 77 | 134.5 | |
| 96.1 | 112.7 | ±60 | 5.5 | 6.6 | ||||
| TIAB SA 3.140 | 126 | 149 | ±50 | 7.5 | 9 | 78 | 146 | |
| 126 | 148 | ±60 | 7.5 | 9 | ||||
| DVTLF 2.250K | 242 | 287 | ±50 | 7.2 | 9 | 79 | 277 | |
| TIAB SA 2.400 | 380 | 455 | ±50 | 11 | 12.5 | 79 | 422 | |
| DVTLF 2.500 | 500 | 575 | ±50 | 15 | 17.3 | 80 | 420 | |
| Qauv NO. | Ceev tus nqi | Qhov kawg siab | Lub cev muaj zog | Suab nrov | Qhov hnyav | |||
| m³/h | KPA | KW | dB (A) | kg | ||||
| 50hz ib | 60hz ib | 50 HZ | 60 tzs | 50 HZ | ||||
| U5.40 XLK | 40 | 48 | 0.1-0.3 | 1 PH | 1.1 | 1.35 | 67 | 28.5 |
| 3 PH | 1.1 | 1.35 | ||||||
| U5.45 | 45 | 54 | 0.05-30 | 1.5 | 1.5-1.8 | 62 | 31 | |
| U5.65 XLK | 65 | 78 | 0.05-30 | 1.5 | 1.8 | 72 | 36 | |
| U5.71 | 70 | 84 | 0.01-10 | 1.5 | 1.8 | 64 | 60.5 | |
| U5.101 | 100 | 120 | 0.01-40 | 2.2 | 2.6 | 65 | 77 | |
| U5.166 | 165 | 198 | 0.01-10 | 3.0 | 3.6 | 70 | 107 | |
| 0.01-40 | 4.0 | 4.8 | 104 | |||||
| U5.201 | 200 | 240 | 0.01-10 | 4.0 | 4.8 | 72 | 102 | |
| 0.01-40 | 5.5 | 6.6 | 121 | |||||
| U5.166 | 165 | 198 | 0.01-10 | 5.5 | 6.6 | 73 | 161.5 | |
| 0.01-40 | 7.5 | 9.0 | ||||||
Peb kuj muab Becker lub tshuab nqus tsev twj tso kua mis qhov chaw: vane, lim, rotor, coupling, coupling disc, hau cap, bearing, cov duab hauv qab no rau koj siv
becker lim
coupling disc
kev sib txuas
Lub hau cap
valve
Cov khoom siv Gasket rau Becker
becker twj kiv cua
twj rotor rau becker
lub dab dej kub
regulating valve
Cim npe nrov: Tuam Tshoj rotary vane nqus tsev twj tso kua mis ntawm becker, Tuam Tshoj teb vane nqus tsev twj tso kua mis becker manufacturers, lwm tus neeg, Hoobkas
